TD5 Bench top low speed centrifuge

  • Product name:TD5 Bench top low speed centrifuge
    Product model:TD5
    Maximum speed:5000r/min
    Maximum capacity:4×250ml
    Product number:TD5 bench top low speed laboratory centrifuge
    Product brand:Herexi/OEM
    Product weight:35Kg
  • product details

Herexi's classic best-selling model, with a variety of tube racks and adapters, used for clinical testing and laboratory analysis.


Product Name: TD5 bench top low speed centrifuge

Max Centrifugalforce:4×250ml

Max Speed(r/min):5000

Max RCF:4800xg

PIN:TD5
Brand:Herexi/OEM
Product unit: set
Weight: 35Kg


Product Details

Main Features


Micro-controller and high-torque brushless motor provide stable operation and low noise.

TFT-LCD true color touch screen and physical button dual operation mode, can change parameters at any time during
operation, the operation menu is available in multiple languages (Chinese, English, Russian, Portuguese).

It has various early warning functions such as over-speed, over temperature, unbalance, under pressure and overpressure,
special damping and shock absorption, which makes the motor run safely and reliably, and achieve excellent centrifugal effect.

The bio-safety airtight angle rotor uses a silicone rubber integral seal (EU RoHS 2015/863) to avoid fully guarantee for the
safety of the staff and laboratory environment.

304 stainless steel centrifugal chamber and whole-steel casing, one-piece stamped steel front face and three-layer steel
protective cover to ensure the safety of workers and laboratories.

With mechatronic motor door lock.

Can store 20 sets of user-defined programs Can be customized according to demand

Aviation forged aluminum rotor (angle rotor only) and a variety of adapters are available, can centrifuge various MTP micro-
plates, PCR plates, cell plates.

With CFDA & CFDA production qualification, ISO 9001, ISO 13485 and CE certification.


Specifications:

Model

TD5

Max speed(r/min)

5000

Max RCF(×g)

4800

Max capacity

4×250 ml

Time range

0-99h59min

Operation programme

20

Control and drive system

Frequency motor,micro control,direct drive

Power

500 w

Noise

≤60 dB

Power

AC220V 50Hz

Weight

35 Kg

dimension(L×W×H)

600×540×360 mm


Model

Capacity

TD5

Max Speed

Max RCF


Swing bucket rotor

4×250ml

4000

2780


24×10/15ml


4000



2960



8×50ml


4000



2960



32×15ml


4000



2960



32×10ml


4000



2960



4×50ml

5000

4600


4×100ml

5000

4800


48×5ml/2ml(vacuum tube)

4000

2940


76×5ml/2ml(vacuum tube)

4000

3100


Swing micro-plate rotor

2x2x96 hole

4000

2360
